JINPIN KU 2204-SE Edge calculation
CPU: Intel® Xeon® Silver 4210 10-core 2.2GHz
Memory: 16GB DDR4 ECC RDIMM
Hard Disk: 2TB SATA 7.2K Enterprise Class
Network: Intel® X722 dual Gigabit network
Power supply: 800W (1+1) platinum redundant power supply
Basic configuration for reference only
Designed according to the "OTII Server Technical Specification", the whole machine has a depth of 450mm, and can work at a temperature between 0°C and 40°C for a long time.
It meets the requirements of carrier-grade EMC and earthquake resistance, and is suitable for mass deployment in edge computer rooms.
Support dual Intel®Xeon®Cascade-Lake expandable processors, 2TB DDR4 RECC memory, excellent computing performance in 2U space,
support 4 3.5-inch SAS/SATA disks, and 2 NVIDIA Tesla T4 GPU acceleration Calculation, small size, great achievements.
Based on the BMC management module, it provides management functions such as SOL, remote KVM, remote power on and off, system monitoring, virtual media mapping,
and deployment of operating systems, thereby simplifying maintenance work, speeding up problem solving, and improving system availability.
|
Specifications |
2U rack type; 89mm × 437mm × 450mm (H × w × d) |
|
CPU |
Intel® Xeon® Scalable calable series processor（TDP 165W） |
|
Chipset |
Intel® C621 |
|
UPI |
10.4 GT/s |
|
Memory |
16 DIMM sockets, supporting 2TB DDR4 3DS ECC rdimm 2400 / 2666 memory |
|
storage |
Four 2.5-inch SAS / SATA 6gbps hot swappable hard disks |
|
RAID |
SATA RAID 0, 1,10,5 |
|
network |
Intel ®X722 dual Gigabit Network |
|
PCIe extension |
2 PCI-E 3.0 x16、1 PCI-E 3.0 x8 |
|
display |
Aspeed AST2500 |
|
Administration |
IPMI 2.0 |
|
Other interfaces |
VGA、4×USB、IPMI、COM |
|
Power Supply |
550W 1+1 platinum power supply |
|
OS |
Windows 10/2012R2/2016/2019 Centos/Redhat 6.9/7.3/7.4/7.5; Suse SLES 11sp4/12sp2 Ubuntu 16.04/18.04; Vmware ESXI 6.5; Xen Server 7.2 |
|
working temperature |
5℃～40℃ |
|
Working humidity |
8%-90％RH |
